Workshop Facilities

Developed Area

3 Hectares

Total Area

3,6 Hectares

Covered Area

Main Workshop Building  :  45m x 126m = 6570m2
Top roof height  :  14 meters
Maximum gantry height  :  10 meters
Painting room  :  31,5m x 54m
Sand blasting Chamber  :  18m x 4,5m x 6m (4 Units)
Platework Building  :  45m x 63m
Packing Building  :  41,4m x 42m
Office  :  15m x 40m

Capacity

800 Metric Tonnes Per Month

Electricity

555 KVA

Equipment

CNC, Iron, Plate, Radial, Crane, Shearing, Generator, etc.

CNC Angle Master

Specification:

  • Model LP.A15.34N "FICEP"
  • Automatic angle punching & shearing system
  • Angle size min. 35x35x3mm, max. 150x150x15mm
  • Process angles up to 14.000 mm length
  • Punching system: 2 punch heads (each 600kn)
  • Punches: max. Ø 30 in 15mm
  • Qty: 1 Unit

CNC Drilling and Cutting Beam

Specification:

  • Model 1103 DEB "FICEP"
  • Web: min 80mm, max. 1115mm
  • Flanges: min. 30mm, max. 610mm
  • Max. Drill Diameter: 40mm
  • Qty: 1 Unit

CNC Flame & Plasma Cutting Plate Machine

Specification:

  • Model Max200
  • Max cutting thickness: 2" (50mm)
  • Max current at 100% duty cycle: 200 amps
  • Length: 6000mm, Width: 2000mm
  • Qty: 1 Unit

CNC Punching Plate Machine

Specification:

  • Model P 83 "FICEP"
  • Maximum hole size: 1-3/4"
  • Maximum punch thickness: 1"
  • Maximum drill thicness: 1-9/16"
  • Qty: 1 Unit

Iron Worker

Specification:

  • Model 1105 N "FICEP"
  • Plate Thickness: 12mm
  • Punch Diameter: 25mm
  • Angle Shear: L 90.90.0
  • Punching system: 2 punch heads (each 600kn)
  • Qty: 4 Unit

Over Head Crane

Specification:

  • Model: A Series "HITACHI"
  • Cap.: 5Ton & 3Ton
  • Qty 5Ton: 9 Unit
  • Qty 3Ton: 14 Unit

Plate Bending Machine

Specification:

  • Hydraulic press brake
  • Model: QC12Y - 160/3200
  • Nominal Force: 1600 KN
  • Max width: 3200mm
  • Max thickness: 8mm
  • Qty: 1 Unit

Profile Bending Machine Up to 5"

Specification:

  • Model APK 101 "AKBEND"
  • Up to 100mm beam/ pipe
  • Qty: 1 Unit

Profile Bending Machine Up to 6"-22"

Specification:

  • Model MCP 3236 "PROMAU"
  • Up to WF 600
  • Up 600mm beam/ pipe
  • Qty: 1 Unit

Radial Drilling Machine

Specification:

  • Model Z 3050x16/1 "SMTCL"
  • Maximal drilling diameter: 50mm
  • Arm: 1600mm
  • Qty: 1 Unit

Roll Plate Machine

Specification:

  • Type W11-D16X2500
  • Maximal thickness 16mm
  • Maximal width 2500mm
  • Qty: 1 Unit

Welded Beam (SAW 1000A)

Specification:

  • Model: MZ-1000
  • Automatic Submerged Arc Welder
  • Wire diameter: 3,0 - 5,0mm
  • Qty: 1 Unit

WShearing Machine

Specification:

  • Model: QC 12Y - 8X3200 "JANGHAI GROUP"
  • Cutting plate machine
  • Hydraulic swing beam shear
  • Max thickness: 8mm
  • Max width: 3200mm
  • Qty: 1 Unit

Equipment List

No ITEM CAPACITY QTY
1 Air Compressor For Sandblasting 250 CFM 2 Unit
2 Air Compressor Cap 15 HP 3 Unit
3 Airless Painting 3.64L/ min 3 Unit
4 Angle Grinder 4" 100 Unit
5 Angle Grinder 6" 63 Unit
6 Angle Grinder 7" 2 Unit
7 Bench Drilling Max Ø 16mm 5 Unit
8 Blasting System 600Lbs 2 Unit
9 CNC Angle Master Max L150x150x15 1 Unit
10 CNC Cutting Plate 1490 x 1190 x 500 1 Unit
11 CNC Drilling Cutting Profile 1400 x 2850 x 650mm / WF 600 1 Unit
12 CNC Flame Cutting 80mm / 12000x2500x500mm 1 Unit
13 CNC Plasma Cutting 50mm / 10000x1800x600mm 1 Unit
14 CNC Punching Plate 25mm 1 Unit
15 Cutting Wheel 355mm/ 14" 4 Unit
16 Cutting Wheel 405mm/ 16" 6 Unit
17 Drilling & Cutting Machine - 1 Unit
18 FCAW Welding Machine 400A 1 Unit
19 FCAW Welding Machine 350A 44 Unit
20 Flame Cutting Torch N/A 30 Unit
21 Forklift 7 Tones 2 Unit
22 Genset 10-90 KVA 12 Unit
23 Hydrolic Drilling Machine 16A 1 Unit
24 Iron Worker - 4 Unit
25 Magnetic Drill Dia 32mm 21 Unit
26 Manual Gas Cutting 80-800mm 220V 4 Unit
27 Manual Gas Cutting 5-100mm 220V 8 Unit
28 Over Head Crane 3 Ton 14 Unit
29 Over Head Crane 5 Ton 9 Unit
30 Pipe Rolling Machine dia 2" 1 Unit
31 Plasma Cutting 200A 3 Unit
32 Plasma Cutting 100A 1 Unit
33 Plasma Cutting 80A 2 Unit
34 Plate Bending Machine 160 Ton / 3200mm 1 Unit
35 Plate Rolling Machine 16mm 1 Unit
36 Profile Roll Machine - 1 Unit
37 Punching Machine 20-24mm 6 Unit
38 Reamer Grinder Ø 6 mm 23 Unit
39 SAW Welding Machine (Welded Beam) 1000A 1 Unit
40 Shearing Machine 8mm / 3200mm 1 Unit
41 SMAW Welding Machine 400A 98 Unit
42 SMAW Welding Machine 350A 20 Unit
43 SMAW Welding Machine 160/ 200A 2 Unit
No ITEM CAPACITY QTY
